DTG2 & DTG3
Gravimetriske Ventiler
DTG2 | 2 WAY GRAVIMETRIC
COMAV’S GRAVIMETRIC DIVERTER VALVE are designed to divert granulate powder and pellets from one to two ways.
Thanks to a two different special execution the 2 way gravimetric valve is also used for abrasive products and in diary making. The DTG2 is an universal valve for all kind of application with many accessories that match the customer’s needs.
APPLICATIONS
Gravimetric discharge
powder
Granulate
Pellets
Diverters
FEATRURES
PRESSURE: ATM
TEMP.: max 100°C
Fly switchRugged life
Long life
DESIGN
SIZE: DN150, DN200, DN250
BODY: Carbon steel, ALUMINIUM, STAINLESS STEEL AISI 304/316L
FLAP: Painted carbon steel, stainless steel AISI 304/316L
SEAL: Teflon
OPERATION: Cylinder or manual
OPTIONALS
Special execution for abrasive product
Inner polished treatment
Food grade approval material
Various chemical treatment on body/flapInspection door with safety key
Size on request
Kit connection pipe
Download DTG2 Brochure
Teknisk Data | DTG2
| A | B | C | D | E | F | G | WEIGHT | |
|---|---|---|---|---|---|---|---|---|
| 150 | 150 | 210 | 195 | 250 | 375 | 470 | 325 | kg – |
| 200 | 200 | 266 | 275 | 340 | 480 | 645 | 380 | kg – |
| 250 | 250 | 316 | 325 | 400 | 565 | 700 | 430 | kg – |
NB. scroll horisontalt for fuld tabeloversigt.
DTG3 | 3 WAY GRAVIMETRIC
COMAV’S GRAVIMETRIC DIVERTER VALVE are designed to divert granulate powder and pellets from one to three ways.
Thanks to a three different special execution the 3 way gravimetric valve is also used for abrasive products and in diary making. The DTG3 is an universal valve for all kind of application with many accessories that match the customer’s needs.
APPLICATIONS
Gravimetric discharge
powder
Granulate
Pellets
Diverters
FEATRURES
PRESSURE: ATM
TEMP.: Max 100°C
Fly switchRugged designLong life
DESIGN
SIZE: DN150, DN200, DN250
BODY: Carbon steel, aluminium, stainless steel AISI 304 or 316L
FLAP: Painted carbon steel, stainless steel AISI 304 or 316L
SEAL: Felt
OPERATION: Cylinder or manual
OPTIONALS
Special execution for abrasive products
Inner polished treatment
Food grade approval materialHigh temperature version
Inspection door with safety key
Inner cone for flowrate reduction
Size on request
Kit connection pipe
Download DTG3 Brochure
Teknisk Data | DTG3
| A | B | C | D | E | WEIGHT | |
|---|---|---|---|---|---|---|
| 150 | 150 | 220 | 450 | 655 | 455 | kg – |
| 200 | 200 | 270 | 450 | 655 | 455 | kg – |
| 250 | 250 | 320 | 500 | 775 | 505 | kg – |
NB. scroll horisontalt for fuld tabeloversigt.
